The compact OM1300 appliance is purpose-built for secure edge deployments – working seamlessly with Lighthouse Management Software. By combining Smart OOB™ access with integrated switch ports for connecting servers, firewalls, and other critical equipment, it delivers a simplified, resilient platform that supports modern network management and automation at remote sites.
- Managed networking with VLAN and Routing support
- IP based device management with Smart OOB™
- 4GB LPDDR4 memory / 32GB eMMC storage
- TPM 2.0 embedded physical security
- 4 port Serial and 4 port Ethernet management OR 8 port Serial and 8 port Ethernet management
| Console Specifications | |
|---|---|
| Serial Ports |
|
| Interfaces | |
|---|---|
| Network Ports | 2 x combo ports - RJ45 100BASE-TX/1000 BASE-T or SFP |
| Managed Switch Ports | 4 x Managed 10/100/1000 Base-T switched Ethernet Ports |
| Local Console Port | 1 x USB-C Console Port - X2 Pinout, default baud rate 9600/8N1 |
| Managed Serial Ports | RJ45 RS-232 Software Selectable Pinout 50 to 115,200 bps |
| USB Ports | 2 x USB 3.0 ports (for mass-storage, device console management) |
| Remote Access | Dual Ethernet, aggregation & redundancy, Automatic Network Failover, Easy browser UI, IPv6 |
| Console Management |
|
| Power Requirements | |
|---|---|
| Power Input | Dual Power inputs, second available as redundancy |
| Power Adapter | 1x Universal 110-240V AC to 12V DC external power adapter IEC 62368, UL, CB, DoE, VI, PSE, LPS certified |
| Cooling | Passive Cooling - can be forward or reverse mounted |
| Physical Dimensions | |
|---|---|
| Dimensions and Weight | 8.66" x 7" x 1.75" - 2.7 lbs, 220 x 177 x 44 mm - 1.45 kg |
| Form Factor | Compact - SFF 1RU half-rack width |
| Memory and CPU | |
|---|---|
| CPU | 1.6 GHz Quad-Core ARM Cortex-A53 SoC |
| Memory | 4GB LPDDR4 SDRAM |
| Storage | 32GB eMMC |
| Environmental | |
|---|---|
| Operating Temperature | 5°C to 50°C, 41°F to 122°F |
| Storage Temperature | -30°C to +60°C, -22°F to +140°F |
| Humidity | 5% to 90% (non-condensing) |
| Environmental Monitoring | Built-in temperature sensor |
| Security, Encryption & Authentication | |
|---|---|
|
| Automation & Scalability | |
|---|---|
|
| Certifications | |
|---|---|
| Safety | IEC 62368-1:2018 |
| Emissions | 47 CFR Parts: 15B, ICES-003 Issue 7, EN55032:2015+A11:2020, AS/NZ, CISPR 32:2015, VCCI-CISPR 32:2016, EN 301 489-1:2019 |
| Immunity | EN55035:2017+A11:2020, EN 61000-3-2:2019, EN 61000-3-3:2013, EN 301 489-52:2021 |
| RoHS | EN 63000:2018 |
| Other Agency Approvals | KS C 9832:2023, KS C 9835:2019, CNS 15936:2016 |
| Warranty | |
|---|---|
| 5 years hardware replacement included. Appliance requires a minimum of 1 year Foundation Support at the time of purchase. |
Available Models
| Model | Description |
|---|---|
| OM1304-4E | 4 x RS232 RJ45 Software Selectable Pinout, 2x 1GbE SFP, 2x 1GbE, ARM 1.6GHz 4-core, 4GB LPDDR4, 32GB flash, TPM 2.0, Single AC |
| OM1308-8E | 8 x RS232 RJ45 Software Selectable Pinout, 2x 1GbE SFP, 2x 1GbE, ARM 1.6GHz 4-core, 4GB LPDDR4, 32GB flash, TPM 2.0, Single AC |
Package Checklist
- Operations Manager OM130X
- Rack Mount Kit (Part# 590054)
- C14 Power Cable (Part# 440055)
- A/C Power Brick (Part# 450047)
Opengear Pinout
Optional Accessories
| Part Number | Description |
|---|---|
| 319014 | Adapter - DB9F to RJ45 straight serial - DCE -For X2 Pinout |
| 319015 | Adapter - DB9F to RJ45 crossover serial - DTE -For X2 Pinout |
| 319016 | Adapter - DB9M to RJ45 straight serial - DCE - For X2 Pinout |
| 440081 | Cable Ethernet CAT6 High Temperature - 5' length |
| 590054 | Rack Mount Kit - Ears and Screws |
| 590059 | Rack Tray Kit - Convert to 1RU full-rack width |
| 450045 | External 60W DC Power Supply, 18-72V DC Universal input, 12V DC output barrel connector - IEC 62368 |
| 450047 | External 65W AC Power Adapter, IEC-C14 inlet, 12V DC output locking barrel connector - IEC 62368 |
Warranty
| Part Number | Description |
|---|---|
| Included | 5 year standard warranty |
| Select one of the following to include with the appliance: | |
| OG-FNTS-OM1300-1YR | 1 year Foundation Support for OM1300 - 8x5 Regional Support with Advanced Replacement |
| OG-FNTS-OM1300-2YR | 2 year Foundation Support for OM1300 - 8x5 Regional Support with Advanced Replacement |
| OG-FNTS-OM1300-3YR | 3 year Foundation Support for OM1300 - 8x5 Regional Support with Advanced Replacement |
| OG-FNTS-OM1300-5YR | 5 year Foundation Support for OM1300 - 8x5 Regional Support with Advanced Replacement |
| OG-FNTS-OM1300-7YR | 7 year Foundation Support for OM1300 - 8x5 Regional Support with Advanced Replacement |
| OG-PRTS-1YR | 1 year Premium Support - Access to Premium Resources 24x7 and Advanced Replacements |
| OG-PRTS-2YR | 2 year Premium Support - Access to Premium Resources 24x7 and Advanced Replacements |
| OG-PRTS-3YR | 3 year Premium Support - Access to Premium Resources 24x7 and Advanced Replacements |
| OG-PRTS-5YR | 5 year Premium Support - Access to Premium Resources 24x7 and Advanced Replacements |
| OG-PRTS-7YR | 7 year Premium Support - Access to Premium Resources 24x7 and Advanced Replacements |
